270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V

$34,200/sets 1-2 sets
가격
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V
풍모 갤러리 제품 설명 따옴표를 요구하십시오
풍모
제품 사양
영상출고검사: 제공
기계 시험 보고서: 제공
핵심 구성요소: 지탱하는 PLC, 엔진, 기어박스, 기어
플라스틱 가공: PP, HDPE, ABS, PVC, PE, EVA, PE/PP, HDPE/PP
원산지: 중국 장쑤성
brand name: DAWSON
전압: 440V/415V/380V/220V
치수(l*w*h): 4.4*3.4*3.6
클램핑 력 (KN): 270
PLC 브랜드: Wisetech
나사 L/D 비율: 24
나사 직경 (mm): 90
출력 (kg/h): 130
오토메이션: 오토매틱
나사 가열 구역 수: 4
스크류 발열량(kW): 10
압출기 모터 동력(kW): 30
형판 크기(너비)(mm): 660
형판 크기(높이)(mm): 680
공기압 (MPA): 0.8
공기 소비량(m³/min): 2.2
다이 헤드 발열량(kW): 8
전력(kw): 67
무게(T): 11.3
주요 판매 포인트: 작동하기 쉬움
보증: 1년
블로우 성형 유형: 압출 블로우 성형기
최대 응용 프로그램 크기: 10~30L
냉각 수압: 0.6 MPa
물 소비량: 100 L/분
파리슨 제어 시스템: M00G 200 포인트
곰팡이 재료: P20, 2316, S136H, 베릴륨 구리가 포함된 알루미늄.
언어 설정: 중국이고 영어 조작 패널
교육은 공급했습니다: 중국과 영어에 관한 교육
노동력의 수요: 1~2 오페레토르
샘플 제공: 필요할 경우에
기본 정보
결제 및 배송 조건
제품 설명
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 0
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 1
10-30L Plastic Jerry Can Extrusion Blow Molding Machine
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 2
Electronic Parts
Parison Control system
MOOG 200 points
Micro computer control system
WISETECH
Temperature Controller
WISETECH
Auxiliary Relay
OMRON
contactor
Schneider
Main Power Switch
Schneider
Approach switch
Schneider
Electric motor
W&N
Inverter
INNOVANCE
Hydraulic Parts
Oil pump
SUMITOMO
Valve
YUKEN
Oil pump and connection
YUKEN
Sealed part
DZ
Air Control System
Cylinder
AIRTAC
Air Valve
AIRTAC


Click here to send us messages >>Send Inquiry...

270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 3
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 4
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 5
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 6
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 7
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 8
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 9
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 10
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 11
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 12
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 13
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 14
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 15
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 16

DAWSON MACHINE & MOULD GROUP

located in Zhangjiagang city, have more than 18 years' experience in the field of plastic machinery,
injection molding machine, blow molding machine, PET blow molding machine, injection blow molding machine, during the past 18 years, we always force our energy into new areas of plastic machinery, plastic packaging machinery, to update the technology, to learn advanced experience, to confirm new theory and new design, we are forming a unique competitive advantage of our owns.
The machines from our company carry good quality and effective after-sales service, upon the market,
customers from more than 45 countries, we provide complete solution for your plastic industry
business, as well as all sorts of technical support & after-sale services!
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 17
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 18
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 19
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 20
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 21
270 kN Clamping Force Plastic Blow Molding Machines for 20L Drum Canister Production Voltage Options 440V 415V 380V 220V 22

Q: Can we visit your factory?
Sure. We located in Zhangjiagang city which is very near Shanghai. For overseas customers, you can fly to Shanghai Pudong International Airport. We can pick you up in the Airport. (or Hongqiao International Airport. ) We also provide visit online by video.

Q: How can we get the exact price of plastic machine?
Contact us with the products size, shape, annual quantity and photo if possible. We can recommend our machine models with quotation.

Q: Do you provide any spare parts with machine?
Yes, we offer all necessary spare parts before shipment.(contact us for packing list )

Q: How about your after-sale service ?
We offer manual instruction and engineer training before loading,after shipment we provide 24 HRS online support, video technical support or field installation assist.

Q: What is the lead time?
For customized machine, it takes about 45-50 days after deposit. For stock machine, fast shipment. ( The actual production cycle will vary according to the degree of customization.)

Q: What is the warranty period for your machine ?
12 months warranty for components and technical support .

Q: Do you provide custom machines?
Most of our machines are customized. Our goal is efficiency and stable performance. We design the machines according to customers products to meet customer' needs.

Q: How can we install the machine when it arrives?
We can send experienced technicians to customer's country for guiding the installation and commission the machine, also train the customer's employees.

Q: What's DAWSON's advantage?
DAWSON provide customers with turnkey projects. Including plant design, plastic machine and mold installation, debugging, also we can source the auxiliary equipment for customers. We can ship the full set of machines after testing in our factory. It will save a lot of cost and time.

DAWSON will be your reliable friend in China, and we will always do our best to give you max support!
